Short Description
Premium factory-direct aftermarket T6EC-062-022-1R00-B1-J224 Double Hydraulic Vane Pump, engineered as a 100% interchangeable drop-in replacement for original Denison / Parker industrial and mobile fluid power systems. Featuring a dual-cartridge configuration (Size E + Size C), this high-volumetric efficiency pump provides quiet operation, superior pressure capability up to 240 bar, and prolonged service life in demanding machinery tasks.
Key Highlights
-
100% Precise Code Interchangeability: Perfectly matches Parker Denison nomenclature T6EC-062-022-1R00-B1-J224. Fits seamlessly into original mounting footprints, keyways, and SAE flange interfaces with zero piping adjustments.
-
Dual-Displacement Versatility: Combines a high-flow 062 cartridge (197.0 ml/r) with a medium-flow 022 cartridge (70.3 ml/r) on a single drive shaft, allowing systems to implement efficient hi-low speed circuits or feed two separate hydraulic circuits simultaneously.
-
Advanced Floating Side-Plate Technology: Utilizing Denison’s signature micro-compensating side plates to optimize volumetric efficiency under high pressures, while significantly decreasing case drainage and inner friction wear.
-
Ultra-Low Noise Signature: The specialized bimetal 12-vane geometry ensures extremely low flow pulsation, making it the premier choice for indoor industrial plants (injection molding, balers) and urban drilling rigs requiring strict noise controls.
Technical Parameters Matrix
| Technical Parameter | Specification Specification |
|---|---|
| Full Model Code | T6EC-062-022-1R00-B1-J224 |
| Brand Compatibility | Denison / Parker Hannifin Hydraulic Platforms |
| Pump Configuration | Double / Dual Vane Pump (E + C Frame Sizes) |
| P1 (Shaft End) Displacement | Size 062 (Approx. 197.0 ml/rev) |
| P2 (Cover End) Displacement | Size 022 (Approx. 70.3 ml/rev) |
| Shaft Design type | Code 1 (Standard Keyed Shaft) |
| Direction of Rotation | R (Right Hand / Clockwise from shaft view) |
| Maximum Pressure Rating | Up to 240 bar / 3500 PSI |
FAQ
Q1: Can I purchase individual T6EC replacement cartridges instead of the whole pump assembly? A: Yes, absolutely. We support both full ready-to-run pump units and standalone replacement core kits. You can source the T6EC-062 shaft-end cartridge or the T6C-022 cover-end cartridge separately along with standard custom viton seal groups for quicker field repair turnarounds.
Q2: Does this T6EC-062-022 pump support synthetic or water-glycol hydraulic fluids? A: The standard model is configured for petroleum-based mineral oils. However, based on the J224 suffix or specific operating requirements, we can customize the internal seals and materials to suit fire-resistant fluids like water-glycols or phosphate esters. Please clarify your medium with our technicians when requesting a formal quote.
